VL-MW251BX/CX/AZ

• Model number and name : Main Monitor Station (Main monitor)
• Power supply : 100 – 240 V AC, 50/60 Hz
• Power consumption : Standby:- Approx. 0.04 A, During operation:- Approx. 0.28 A
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 190 x 165 x 38 mm
• Weight : Approx. 785 g
• Operating environment : 0°C to 40°C, Up to 90 % RH (Relative Humidity) non condensing
• Display : Approx. 5-inch, wide colour display
• Frequency : 2.402 GHz – 2.481 GHz
• Installation method : Wall mount(Wall mount bracket included)
• External material : Flame retardant ABS resin

VL-V522L

• Model number and name : Door Station (Doorphone)
• Power supply : Supplied by the Main Monitor Station
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 131 x 99 x 36.5 mm
• Weight : Approx. 200 g
• Operating environment : -10°C to 50°C, Up to 90% RH (Relative Humidity) non condensing
• Viewing angle : Horizontally:- Aprrox. 87, Vertically:- Approx. 66°
• Installation method : Wall mount (Wall mount base included)
• Minimum illuminance required : 1 x (within approx. 50cm from the camera lens)
• Lighting method : Warm white LED lights, Infrared LEDs
• IP rating/IK rating : IPX3*1
• External material : Flame retardant ABS resin

VL-W605BX/CX/AZ – (Main body)

• Model number and name : Wireless Monitor (Sub monitor station)
• Power supply : Ni-MH battery (3.6 V DC / 650 mAh)
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 157 x 52 x 35 mm
• Weight : Approx. 175 g (including the battery)
• Operating environment : 0°C to 40 °C, Up to 90% RH(Relative Humidity) non condensing
• Display : 1.8″ colour LCD monitor
• Frequency : 2.402 GHz – 2.481 GHz
• External material : ABS resin

VL-W605BX/CX/AZ – (Charger)

• Model number and name : Wireless Monitor (Sub monitor station)
• Power supply : AC adaptor, VL-W605BX: POLV219BX (100-240 V AC, 50/60 Hz), VL-W605CX: PQLV219E (220-240 V AC, 50/60Hz), VL-W605AZ: PQLV219AZ (220-240 V AC, 50/60 Hz)
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 115 x 76 x 90 mm, Approx. 105 x 76 x 48 mm(using without the stand)
• Weight : Approx. 115g (including the stand)
• Operating environment : 0°C to 40 °C, Up to 90% RH (Relative Humidity) non condensing
• External material : ABS resin

VL-FAN1BX/CX

• Model number and name : Optional Repeater for Wireless Monitor
• Power supply : AC adaptor (100 – 240 V AC, 50/60 Hz), VL-FAN1BX: 2 pin AC plug, VL-FAN1CX: 3 pin AC plug
• Power consumption : Standby:- Approx. 0.05 A, During operation:- Approx. 0.08 A
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 27 x 101 x 82 mm, Approx. 69.5 x 101 x 82 mm(when raising the antenna)
• Weight : Approx. 85 g
• Operating environment : 0°C to 40°C, Up to 90% RH (Relative Humidity) non condensing
• Frequency : 2.402 GHz – 2.481 GHz
• External material : Flame retardant PS resin

VL-V590BX/CX

• Model number and name : Optional Lobby Station
• Power supply : 100V-240 V AC, 50/60 Hz, VL-V590BX: 2 pin AC plug, VL-V590CX: 3 pin AC plug
• Power consumption : Standby:- Approx. 0.02 A, During operation:- Approx. 0.03 A
• Dimensions (H x W x D)(Excluding protruding sections) : Approx. 358 x 180 x 17.3 mm(Excluding sections embedded into the wall)
• Weight : Approx. 2.0 kg
• Operating environment : -10°C to 50°C, Up to 90% RH(Relative Humidity) non condensing
• Viewing angle : Horizontally: Aprrox. 87, Vertically: Approx. 66
• Installation method : Wall mount(Flush mounted box included)
• External material : Stainless steel and flame retardant ABS resin
