  • Near the wireless router, plug one end of the enclosed Power adapter into the Power Jack of EasyN cam, and the other end of the Power adapter into the wall outlet.
  • When camera finish rotating and Ding-Dong tone comes out, it means that ipcam is waiting for receiving Wi-Fi signal (If you connect camera with Ethernet cable, there will not be any Ding-Dong tone coming out from camera).
  • Make Wi-Fi available on your mobile phone.

Note: when ipcam is in the initial state, there is Ding-Dong tone coming out from it.

    Here are three methods to suspend the Ding-Dong tone:

  • Just connect your ipcam to the router with Ethernet cable;
  • Connect your ipcam to the router with smart-config method;
  • Power off the ipcam

This WiFi camera features in P2P plug and play, auto-focus 2.8-12mm lens, HD 960P video recording, and it’s equipped with 22 infrared LED lights, and built in IR-CUT, no color cast, which provides good day and night vision. It is also with functions of motion detection, waterproof, TF card slot, and phone APP control, etc. It is a good choice for home, shop, office and other needed places.

    Features

  • HD 1/3″ CMOS 1.3 megapixel 960P, waterproof WiFi camera.
  • H.264 video compression, higher definition image and lower bit rate.
  • P2P cloud function, peer to peer connection, no need port mapping.
  • Multiple ways to access on the PC and phone, can be viewed by PC client, Phone APP.
  • For Android/iOS mobile devices remote view anywhere anytime.
  • Built in IR-CUT, no color cast. Auto switch between day and night, restoring clear true color.
  • 22pcs IR LED lights, can get clear images at night, IR distance up to 20m.
  • TF card slot, support up to 128G TF card storage, built-in 16GB TF Card.
  • Auto-focus 2.8-12mm lens. Pan tilt rotation, 355°horizontal / 90°vertical, no blind spot.
  • Support two way audio input output.
  • Motion detection function. When the camera detects something moving, it will push notification to your phone APP

Specification

  • Power Supply: DC 12V 1A
  • Pixel: 1.3 Mega Pixel
  • Resolution: (1280*960), VGA(640*352), QVGA(320*176)
  • Sensor: 1/3″ CMOS
  • Lens: Auto-focus 2.8-12mm lens, 5X optical zoom, 3X digital zoom
  • Audio: Support two way audio input output.
  • Infrared lamp: 22 lamps
  • Infrared distance: 20M
  • IR-CUT filter: Auto switch
  • Pan & Tilt: Horizontal:355°, Vertical:90°
  • Compression format: H.264
  • Protocol: Support TCP/IP, HTTP, ICMP, DHCP, FTP, SMTP, PPPoE, etc.
  • WIFI Connection: Support
  • Wireless standards: IEEE 802.11B/G/N
  • Phone APP: For Android / iOS
  • PC CMS: Windows XP, Win7, Win8, Win10, Win98 , Vista
  • Browser: IE, Firefox, Chrome, for Edge, Safari, etc
  • Recording type: TF card , support 24 hours continuous recording
  • Micro SD size: Support up to 128G TF card, built-in 16GB TF Card
  • Onvif: Support
  • Working temperature: -10°C to +50°C
